Exheat FP4-3-6-18-FS3-SO in BULGARIA

Brand: Exheat

Country: Bulgaria

Description : Flameproof Fixed Rod Type Water Immersion Heater

Technical specification : Capacity 6kW – client specified Voltage 400V, 3Ph, 50/60Hz (3-W STAR with Floating Neutral) Fixing 3” NB 150lb ANSI RF Blind 316L St Steel Flange Immersed Length 450mm of which 50mm is inactive Cable Entries 1 x M25 & 1 x M20 complete with temporary plugs (terminals suitable for 4mm² as standard, please advise if larger supply cable is to be used) Protection ATEX / IECEx Certified Ex II 2 G D Ex d IIC T3 Gb Zone 1 & 2 Ex tb IIIC T200°C Db Zone 21 & 22 Certificate Number LCIE 01 ATEX 6056X IECEx LCI 06 0006X Enclosure Powder Coated Mild Steel Weatherproof IP66 Elements 3 off 10mm diameter 316L Stainless Steel Rod Type Stand Off 100mm Bundle Diameter 50mm Watts Density 7.9W/cm² Controls (VAC) (S1) 1 off Auto Reset Control Thermostat range +0/+120ºC – set at +80°C (5-7°C hysteresis) (S2) 1 off Manual Reset Over-Temperature Limit Thermostat set at +140°C (S3) 1 off Manual Reset Box Cut Out set at +80°C, located within the terminal box to prevent overheating Test Pressure 20 Bar g Working Pressure 13 Bar g Weight approx. 12kgs each Suitable for ambient temperatures of -40°C to +60°C. For ambient temperatures from -40°C to -60°C, an additional ACH will be required. Please advise sales if your ambient temperature is within this range to ensure your design is suitable.

Condition: New (Unused)
