Dietz-Motoren R27-2176-NK-035/055-4_8 in UNITED STATES

Brand: Dietz-Motoren

Country: United States

Technical specification : Engine torque 4.69 / 3.69 Nm Output torque 128-128-52 / 128-128-41 Nm Engine rpm 712.5 / 1425 1 / min Output speed 7,5-22-53 / 15-34-105 1 / min Motor power 0,35 / 0,55 kW Load factor from 0.43 to 2.5 / 0.55 to 3.1 Shaft type Solid shaft with keyway Output bearing reinforced bearing Shaft dimension Ø 22x 60 VP * 210484 Housing design Feet finish Mounting position IMB3 Output shaft seal double Adjustment Handverst.links Skalensch. * Adjusting handwheel with scale housing Scale 1 - 10 * 22252 R27 + R57 Drive cone bore Ø 19 Lubrication Mobilgear 600 XP 220 * CLP ISO VG 220 Material number 846 076 size BG080 Number of poles 8/4 pole Power 0.35 / 0.55 KW Motor designation K20R80K8-4 / B20R80K8-4 Option Design Standard * Voltage fixed voltage - + 5% Circuit D / YY frequency 50Hz Voltage 400 V Ambient temperature -15 to + 40 ° C Standard Thermal class 155 (F) IP56 Thermal motor protection thermal contact NC self-ventilated Cooling S1 mode operation KLK- / connector position KLK 180 ° Cable entry left Option motor nameplate KLK and nameplate STÖBER Log Paint W / 2-Komp.Gr + 2-Comp. Deckl. Color RAL 9006 white aluminum Lackieroptionen Complete painted Documentation language German Documentation English

Condition: New (Unused)
