Itron Meter type SL761 in TURKEY

Brand: Itron

Country: Turkey

Description : Original Spare Part

Technical specification : Static 3-phase 4-wire meter for internal measurement of active, reactive and apparent power in each direction, and separately per phase; acc. IEC 61036 (active cl.1), IEC 60687 (active cl. 0,2S and cl. 0,5S) and IEC 61268 (reactive cl.2) • Total and per phase energy registers • Internal clock; back up via Super-Cap or battery • IR interface acc. IEC1107 • Electrical interface RS-232 • Protocoll standard acc. COSEM/DLMS; • ID system acc. OBIS • Operational logbook • Dimensions acc. DIN43859 • Operating temperature range –25 ºC to +55 ºC • Limited operation temperature range –40 ºC bis +70 ºC Tariffication and load profileTarifregister (Ressource Level 1) • Energy: 3 channels with 10 registers • Power: 3 channels with 7 registers • Load profile with 3 channels Inputs/Outputs (Light I/O) • 1 Control input 3-Phase / 4- wire meter for current and voltage transformer connection • Nominal voltage 3 x 58/100 V • Nominal / rated current 5(10) A • cl. 0,5 (active); cl. 2,0 (reactive • 2 Control outputs • 2 Pulse outputs • 2 Pulse inputs

Condition: New (Unused)
