Ultra Pompe S.r.l. PGLG--42VVV----GS--M4100L in TURKEY
Get the best sales prices in TURKEY for Ultra Pompe S.r.l. PGLG--42VVV----GS--M4100L from Ontrium.
Product: PGLG--42VVV----GS--M4100L
Brand: Ultra Pompe S.r.l.
Country: Turkey
Description : GL 42 V with lantern and coupling
Technical specification : G series gear pump
B5 lantern mounting
Complete of lantern and coupling
Displacement 42 cc/rev
Mechanical seal made of stainless steel/carbon
graphite/FPM
External lip seal FPM
Gasket FPM
Pump made of cast iron G25
Rotors carbon steel 39NiCrMo3 nitridin process
Bearings stainless steel/PTFE
To be coupled to electric motor IP 55 IE2 Class F V
400/50 480/60 4 Poles KW 2,2 B3/B5 100L
Rated speed 1400 rpm
Theoric delivery (1bar, 220 cSt) 58,8 l/min
Operating pressure and viscosity limited by drive
power
Design pressure 30 bar
Operating pressure 10 bar
Operating viscosity 100 cSt
Operating temperature ambient
Condition: New (Unused)
We supply high quality PGLG--42VVV----GS--M4100L products for your new projects or which you may use to recover your broken equipment.
A member of our experts will get the cheapest sales prices for products of Ultra Pompe S.r.l. - PGLG--42VVV----GS--M4100L GL 42 V with lantern and coupling in Turkey.Minimize your expenses with the high quality products of Ultra Pompe S.r.l..Our job is to save you time and minimize your expenses on spare parts and industrial components.Our company is not an official distributor of Ultra Pompe S.r.l., but we are selling their products at competitive prices.Buy the original product of Ultra Pompe S.r.l. - PGLG--42VVV----GS--M4100L GL 42 V with lantern and coupling in Turkey at reasonable price.Don’t hesitate to become one of our customers, you will not regret it!You may fill out our request form or send your enquiry by e-mail.Our company is not an authorized distributor or representative for this brand. We are a reseller company for this brand.
Other products from Ultra Pompe S.r.l.
GEAR PUMP GL-35-VB – 1,5KW 4P
- Description: Pump with lantern, coupling and drive
Electric motor 1,5 Kw 4 Poles B3/B5 90L 400/50- 480/60
Cast Iron Pump
Rotation CW
Internal safety valve
FPM sealing elements.
Mech. seal made of Stainless Steel – Carbon Graphite –FPM + lip seal FPM
Displacement: 35 cc/rev Rated speed: 1400 rpm Theoric delivery:
at 1 bar
49 l/min
Max. Temperature: --°c Max. Pressure: -- bar Viscosity range: -- cSt
GEAR PUMP GL-35-VBS – 1,5KW 4P
Description: Pump with lantern, coupling and drive
Electric motor 1,5 Kw 4 Poles B3/B5 90L 400/50- 480/60
Cast Iron Pump
Rotation CCW
Internal safety valve
FPM sealing elements.
Mech. seal made of Stainless Steel – Carbon Graphite –FPM + lip seal FPM
Displacement: 35 cc/rev Rated speed: 1400 rpm Theoric delivery: 49 l/min
at 1 bar
Max. Temperature: --°c Max. Pressure: -- bar Viscosity range: -- cSt
GEAR PUMP GL-42– 1,1KW 6P
Pump with lantern, coupling and drive
Electric motor 1,1 Kw 6 Poles B3/B5 400/50- 480/60 90L
Cast Iron Pump
Internal safety valve
FPM sealing elements.
Mech. seal made of Stainless Steel – Carbon Graphite –FPM + lip seal FPM, Displacement: 42 cc/rev Rated speed: 900 rpm Theoric delivery:
at 1 bar -220 cSt
37 l/min
Max. Temperature: --°c Max. Pressure: 10 bar
GEAR PUMP GL-42– 3KW 4P
Pump with lantern, coupling and drive
Electric motor 3 Kw 4 Poles B3/B5 400/50- 480/60 100L
Cast Iron Pump
Internal safety valve
FPM sealing elements.
Mech. seal made of Stainless Steel – Carbon Graphite –FPM + lip seal FPM
Displacement: 42 cc/rev
Max. Temperature: --°c
Rated speed: 1400 rpm
Max. Pressure: -- bar
Theoric delivery:
at 1 bar
59 l/min
Viscosity range: -- cSt
GEAR PUMP GL-52-VB – 1,5KW 8P
Pump with lantern, coupling and drive Electric motor 1,5 Kw 8 Poles B3/B5 400/50- 480/60 112M Cast Iron Pump Internal safety valve FPM sealing elements. Mech. seal made of Stainless Steel – Carbon Graphite –FPM + lip seal FPM, Displacement: 52 cc/rev Rated speed: 700 rpm Theoric delivery: at 1 bar -220 cSt 36 l/min Max. Temperature: --°c Max. Pressure: 10 bar
GEAR PUMP GL-93-VB – 4KW 4P
Pump with lantern, coupling and drive
Electric motor 4 Kw 4 Poles B3/B5 400/50- 480/60 112M
Cast Iron Pump
Internal safety valve
FPM sealing elements.
Mech. seal made of Stainless Steel – Carbon Graphite –FPM + lip seal FPM
Displacement: 93 cc/rev
Max. Temperature: --°c
Rated speed: 1400 rpm
Max. Pressure: -- bar
Theoric delivery:
at 1 bar
130 l/min
Viscosity range: -- cSt
GL 144 V B
PUMP TYPE: GEAR, DISCHARGE PRESSURE: 10 BAR, DIRECTION OF ROTATION CLOCKWISE WHEN VIEWED FROM MOTOR DRIVE END, APPLICATION: FOR COLD SHEAR LUBRICATION, RM-5
GL 144 VB
pump with lantern and coupling
GL-14-VBS
Gear pump
GL-28-VB + 1,5KW 4P
Gear pump
GL-28-VBS + 1,5KW 4P
Gear pump
PGLM---7VVVE---GG--M6-71B
gear pump
LF 21 B
Gear pump
LF 28 AB
Gear pump
LF10B.
Q:0.87m3/h P:10bar 1100rpm 0.5kw
LF21B.
Q:1.8m3/h P:10bar 710rpm 0.75kw
LF44B Q:3.8
Original Spare Part
LF93B Q:120
Original Spare Part
SL-14-V-WNGear pump with lantern (no coupling, no drive)
Original Spare Part
24602
gear pump NMFH 14 Tag NO 8P-105
